- Pulling capacity 85 kN (8,5 tons)
- Ideal for tractors 66 to 103 kW (90 - 140 hp)
- Automatic safety brake
- 3-point hitch as standard
- Weight 880 kg
- Logging plate width 2,06 meters
- Cableguard prevents derailment
- Radio control is optional
- Double clutch
- Adjustable height of pulling point
- Electrohydraulic high pressure operation with self-contained hydraulics is standard
- Maintains high pressure during winching
- High-capacity drum
- Excellent spooling characteristics
- Close to tractor permits heavy loads
- High line pull throughout haul
- Specially made topstay for extra ground pressure
Specifications
- Max pulling capacity / empty drum: 85 kN (8,5 tons)
- Max pulling capacity / full drum: 43,4 kN (4,3 tons)
- Number of drums: 1
- Wire rope, theoretical capacity: 100 m, 14 mm
- Recommended wire rope length: 80 m, 12 mm
- Pulling speed at 540 rpm: 0,48 – 0,82 m/s
- Ratio: 1:12,3
- Necessary power input: 51 kW (ISO 6687)
- Braking power: Min 106 kN (10,6 tons)
- Controls: Electrohydraulic high pressure operation with self-contained hydraulics is standard
- Clutch: Double clutch with replaceable friction plates
- Brake: Automatic safety brake
- Mounting: 3-point hitch with enforced topstay
- PTO input, distance from ground: 60 cm
- Height/ Width/ Depth: 230 / 206 / 80 cm
- Weight (without wire rope): 880 kg
