- Pulling capacity 65 kN (6,5 tons)
- Ideal for tractors from 45 to 90 kW (60 - 120 hp)
- 3-point hitch as standard
- Weight 615 kg
- Logging plate width 1,95 meters
- Cableguard prevents derailment
- Radio control is optional
- Adjustable height of pulling point
- Electrohydraulic high pressure operation with self-contained hydraulics is standard
- Maintains high pressure during winching
- High-capacity drum
- Good spooling characteristics
- Close to tractor permits heavier loads
- High line pull throughout haul
Specifications
- Max pulling capacity / empty drum: 65 kN (6,5 tons)
- Max pulling capacity / full drum: 35,6 kN (3,6 tons)
- Number of drums: 1
- Wire rope, theoretical capacity: 97 m, 12 mm / 80 m, 13 mm (ISO 6687)
- Recommended wire rope length: 50 m, 12 mm
- Pulling speed at 540 rpm: 0,64 – 1,2 m/s
- Ratio: 1:9
- Necessary power input: 46,2 kW (ISO 6687)
- Braking power: Min 81 kN (8,1 tons)
- Controls: Electrohydraulic high pressure operation with self-contained hydraulics is standard
- Clutch: Single friction plate
- Brake: Automatic safety brake
- Mounting: 3-point hitch
- PTO input, distance from ground: 57 cm
- Height/ Width/ Depth: 230 / 195 / 82 cm
- Weight (without wire rope): 615 kg
