- Pulling capacity 50 kN (5 tons)
- For small to medium sized tractors 37 to 60 kW (50 - 80 hp)
- Ratchet brake
- Mechanical control
- 3-point hitch as standard
- Weight 285 kg
- Logging plate width 1,50 meters
- Cableguard prevents derailment
- Radio control is optional
- Range of quick-mount attachments are available as option
- Large logging plate
- Height adjustable PTO-shaft for good adaptation to different tractor sizes
Specifications
- Max pulling capacity / empty drum: 50 kN (5 tons)
- Max pulling capacity / full drum: 20 kN (2 tons)
- Number of drums: 1
- Wire rope, theoretical capacity: 83 m, 11 mm
- Recommended wire rope length: 50 m, 11 mm
- Pulling speed at 540 rpm: 0,63 – 1,62 m/s
- Ratio: 1 : 6
- Necessary power input: 37 Kw
- Braking power: Min 62,5 kN (6,25 tons)
- Controls: Standard cord operation
- Clutch: Replaceable friction pads
- Brake: Ratchet brake
- Mounting: 3-point hitch
- PTO input, distance from ground: 40 cm, adjustable (4 positions)
- Height/ Width/ Depth: 148 / 150 / 46 cm
- Weight (without wire rope): 285 kg
